CVO™ Road Glide™ ST

Spesifikasi Terperinci

• Dimensi

  add remove
  • Panjang
    2410 mm
  • Tinggi Jok
    720 mm
  • Garpu (kepala kemudi) (derajat)
    26
  • Jejak
    170 mm
  • Jarak roda
    1625 mm
  • Ban, spesifikasi depan
    130/60B19 M/C 61H
  • Ban, spesifikasi belakang
    180/55B18 M/C 80H
  • Kapasitas bahan bakar
    22.7 l
  • Kapasitas oil (dengan filter)
    4.7 l
  • Bobot, saat dikirim
    363 kg
  • Bobot, berfungsi baik
    380.11 kg
  • Luggage capacity – volume
    2.42 cu ft (0.069 m3)
  • Tire, type
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Mesin

  add remove
  • Mesin
    Milwaukee-Eight® 121 High Output
  • Diameter
    103.5 mm
  • Jarak piston
    117.5 mm
  • Kapasitas
    1977 cm³
  • Rasio kompresi
    11.4:1
  • Sistem bahan bakar
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Pembuangan
    2-1-2 dual exhaust, Titanium mufflers with carbon fiber end caps
• Performa

  add remove
  • Metode Pengujian Torsi Mesin
    J1349
  • Torsi mesin
    197 Nm
  • Torsi mesin (RPM)
    4000
  • Sudut kemiringan, kanan (derajat)
    32
  • Sudut kemiringan, kiri (derajat)
    32
  • Fuel economy testing method
    Estimated City/Hwy
  • Fuel economy
    44 mpg (5.3 l/100 km)
• Powertrain

  add remove
  • Penggerak utama
    Chain, 34/46 ratio
  • Rasio roda gigi (menyeluruh) Ke-1
    10.233
  • Rasio roda gigi (menyeluruh) Ke-2
    7.093
  • Rasio roda gigi (menyeluruh) Ke-3
    5.268
  • Rasio roda gigi (menyeluruh) Ke-4
    4.266
  • Rasio roda gigi (menyeluruh) Ke-5
    3.635
  • Rasio roda gigi (menyeluruh) Ke-6
    3.067
• Sasis

  add remove
  • Garpu Depan
    47 mm Inverted 1x1 Front Forks with adjustable preload, compression damping and rebound damping
  • Shock Belakang
    Emulsion suspension with adjustable preload, compression damping and rebound damping
  • Roda, jenis depan
    Black, 7-spoke Cast Aluminum
  • Roda, jenis belakang
    Black, 7-spoke Cast Aluminum
  • Rem, Jenis Rotor
    Wave Style, dual floating rotors (front), fixed rotor (rear)
  • Rem, jenis kaliper
    32 mm, 4-piston fixed dual radially mounted front, and single axially mounted rear
• Infotainment

  add remove
  • Screen size
    12.3 in
  • Infotainment system
    Skyline™ OS
  • Jenis
    Full Color TFT
  • Watts per channel
    125
  • Speakers
    4
  • Speaker size
    Two 6.5in fairing speakers, and two 5x7in saddlebag speakers
  • AM
    Standard
  • FM
    Standard
  • SD Card, Flash Drive and MP3 - via USB Connection
    Supported
  • Bahasa
    Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese (Brazil/Portugal), Romanian, Russian, Siamese (Thai), Slovak, Spanish (Mexico/Spain), Swedish, Tagalog, Turkish, Vietnamese
  • Hands-free mobile phone — via Bluetooth
    Standard
  • Voice recognition: phone functions only
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation
    Phone dependent
  • Text-to-Speech (TTS) languages
    Phone dependent
  • Rider / passenger intercom
    Standard (Passenger Headset Sold Separately)
  • Layar informasi kendaraan (suhu udara, tekanan oli, dan eitms)
    Standard
  • USB
    USB-C/MTP/iPod/iPhone, any device with proper adapters to the electric power outlet located in the inner fairing storage
  • Bluetooth
    Phone/Media Player, Headset
• Pilihan warna

  add remove
  • Rally Red
  • Mercury Silver
  • Hot Lap
